BT approved slide out block paviour covers

A range of BT approved block paviour covers and frames particularly suited to town centre developments.

BT Approved steel access cover render

Features

  • Covers have been approved for use by telecommunications companies such as Openreach and Virgin Media.

    BT approved

  • Hot dipped galvanised for corrosion resistance.

    Galvanised

  • Designed with tapered sides and centralised lifting points to allow the cover to slide out of the frame.

    Slide out cover

Block infill

Stock code Range Overall top of frame Overall base of frame Clear opening
(mm)		 Frame depth
(E)		 No. lids Chamber ref My Wrekin
C231N/072025/BT 825 mm x 335 mm 885 mm x 415 mm 725 x 255 86 mm 1 2
C233N/091044/BT 980 mm x 520 mm 1,075 mm x 605 mm 915 x 445 86 mm 3 4
C232N/061061/BT 695 mm x 680 mm 770 mm x 770 mm 610 x 610 86 mm 2 5
C234N/131061/BT 1,380 mm x 683 mm 1,470 mm x 770 mm 1,310 x 610 86 mm 4 6
C236N/228071/BT 2,360 mm x 783 mm 2,445 mm x 870 mm 2,285 x 710 86 mm 6 10
C235N/169071/BT 1,765 mm x 783 mm 1,850 mm x 870 mm 1,690 x 710 86 mm 5 11
C233N/096061/BT 1,040 mm x 683 mm 1,120 mm x 770 mm 960 x 610 86 mm 3

Concrete infill

Stock code Range Overall top of frame Overall base of frame Clear opening
(mm)		 Frame depth
(E)		 No. lids Chamber ref Options My Wrekin
C261N/061061/BT 702 mm x 702 mm 610 x 610 46 mm 1
C261N/072025/BT 817 mm x 347 mm 725 x 255 46 mm 1
C261N/091044/BT 1,007 mm x 537 mm 915 x 445 46 mm 1
C262N/131061/BT 1,402 mm x 702 mm 1,310 x 610 46 mm 2
C263N/170710/BT 1,797 mm x 802 mm 1,705 x 710 46 mm 3
C263N/232074/BT 2,411 mm x 834 mm 2,319 x 742 46 mm 3

Related case studies

Related case study

Lord's Cricket Ground

Wrekin Products were approached by consultant Buro Happold to discuss the redevelopment of the Compton and Edrich Stands at Lords Cricket Ground, St John Wood, London.  The redevelopment proposed, required two bespoke covers that could interact with pre-existing valves and hydrants below. Both covers would need to satisfy Thames Water and Fire Brigade specifications.
Lords Cricket Ground
Lords Cricket Ground
Read more
Related case study

Bespoke steel cover at centre of new Sidmouth amphitheatre

Wrekin is proud to have created a bespoke decorative steel manhole cover as part of a significant flood alleviation scheme in a stunning new amphitheatre setting in Sidmouth, Devon. The unique cover is the focal point at the heart of the new flood storage area which doubles as an outdoor performance and event space for the community.

Devon County Council
Devon County Council
Read more
