Solid top pressed

Our pressed mild steel access covers and frames are available in a comprehensive range of sizes and loadings. Hot-dipped galvanising to BS EN IS0 1461 provides corrosion resistance. This range of covers provides a cost-effective solution for infrequent and slow-moving traffic situations. The raised surface pattern is designed to avoid water pooling.

Our solid top steel access covers are available with both a pressed and chequer pattern.

Solid top

PRESSED CORNER COVER

Pressed corner feature

The notch-less, die-drawn corners on our pressed tops provide a continuous surface seal, giving the following benefits:

  • No sharp exposed edges.
  • No cut exposed edges improve corrosion resistance.
  • Better for avoiding water ingress and odour egress

Features

  • Hot dipped galvanised for corrosion resistance.

    Galvanised
  • Keyway lifting points are provided on the frame for safe handling.

    Keyway lifting point in the frame
Single seal solid top cover

Single seal products

The design of our single seal  on these solid top access covers is achieved through an uninterrupted labyrinth between the cover and the frame.

By applying grease to the labyrinth of the frame, the seal's performance improves, providing a mild to moderate defense against the release of gases and the infiltration of water at standard atmospheric pressure.

For increased sealing capacity our double sealed version should be considered.

Single seal products

Single seal is achieved by a simple labyrinth arrangement enhanced by the continuous surface of the cover at the corners. The labyrinth can be filled with grease providing a low to moderate level of resistance to gaseous and/or liquid ingress and/or egress under normal atmospheric pressure.

Stock code Clear opening
(mm)
Overall top of frame
(mm)
Frame depth
(mm)
Load duty My Wrekin
C211K/030030PSF 300 x 300 325 x 325 26 Pedestrian
C211K/045045PSF 450 x 450 475 x 475 25 Pedestrian
C211K/060045PSF 600 x 450 625 x 475 25 Pedestrian
C211K/060060PSF 600 x 600 625 x 625 25 Pedestrian
C211L/045045PSF 450 x 450 475 x 475 25 Domestic light duty
C211L/060045PSF 600 x 450 625 x 475 25 Domestic light duty
C211L/060060PSF 600 x 600 645 x 645 25 Domestic light duty
C211M/060045PSF 600 x 450 625 x 475 25 Light / medium duty
C211M/060060PSF 600 x 600 625 x 625 25 Light / medium duty
C211MP/060045PSF 600 x 450 625 x 475 25 Light / medium duty
C211MP/060060PSF 600 x 600 625 x 625 25 Light / medium duty
C211N/060045PSF 600 x 450 625 x 475 25 Medium duty
C211N/060060PSF 600 x 600 625 x 625 25 Medium duty
Double seal pressed top

Double seal products

The double seal configuration is achieved with an innovative design that utilises a captive 'O' ring, laterally compressed within a purpose-built channel featuring a lip, which is further enhanced by the uninterrupted edge of the cover.

An additional layer of sealing is provided by a supplementary gasket that is compressed vertically within the channel.

Together, these seals offer a superior barrier against the entry or escape of gases and liquids at standard atmospheric pressure.

Double seal products

This range of pressed steel covers come with steel frames and are available in a comprehensive range of sizes and weight loadings. Galvanised to BS EN ISO 1461, this range provides a cost effective solution for the infrequently trafficked environment.

Stock code Clear opening
(mm)
Overall top of frame
(mm)
Frame depth
(mm)
Load duty My Wrekin
C221K/060045PSF 600 x 450 630 x 480 25 Pedestrian
C221K/060060PSF 600 x 600 630 x 630 25 Pedestrian
C221L/060045PSF 600 x 450 630 x 480 25 Domestic light duty
C221L/060060PSF 600 x 600 630 x 630 25 Domestic light duty
C221M/060045PSF 600 x 450 630 x 480 25 Light / medium duty
C221M/060060PSF 600 x 600 630 x 630 25 Light / medium duty
Bespoke steel solutions

Bespoke steel solutions

We offer a comprehensive range of bespoke steel products and services. We work with you to understand your project requirements and are happy to attend site surveys and provide bespoke CAD design services where required.

Our range includes headwall products including trash screens, raked gratings, hand railing systems and sewers for adoption compliant safety grilles, to ladders, steps iron, safety chains and signs.
